FR42 Desktop Scanner

Roll over image to zoom in
Click to open expanded view

Product specifications

Decode Capability 1D, 2D
Connectivity Corded
Dimension 82.0×77.0×146.0mm
Weight 246g
Sealing IP52
Interface USB
Category:

1.5m Drop Resistance

The scanner withstands multiple 1.5m drops to concrete (for six sides, one drop per side).

IP52-rated Sealing

An IP52-rated seal protects the scanner against the ingress of dust, water and other contaminants

IR Trigger

The IR sensor in the scanner enables speedy capture of barcodes presented to it, markedly increasing throughput and productivity.

Snappy On-screen Barcode Capture

Armed with Newland’s latest technology, this scanner is capable of reading 1D as well as high-volume 2D barcodes on a screen covered with protective film.

Superior Motion Tolerance

Exceptional motion tolerance (2m/s) and large FOV (horizontal 62°, vertical 48°) enhance user experience.

Specifications

Performance
 Image Sensor 640×480 CMOS
Illumination White LED
Symbologies 2D: PDF417, QR Code, Data Matrix, Micro QR, etc..
1D:Code 11, Code 128, Code 39, Code 32 (Italian Pharma Code), GS1-128, AMI 128, Codabar, Code 93, UPC-A, UPC-E, EAN-13, EAN-8, ISSN, ISBN, Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, ITF-14, ITF-6, Standard 2 of 5, MSI-Plessey, Plessey, GS1 Databar, etc.
Resolution ≥3mil
Typical Depth of Field EAN-13: 5mm-145mm (13mil)
QR Code: 5mm-195mm (15mil)
Scan Angle Pitch: ±55°, Roll: 360°, Skew: ±65°
Min. Symbol Contrast 25%
Field of View Horizontal 62°, Vertical 48°
Motion Tolerance 2m/s
Scan Mode Sense mode, continuous mode



Physical
 Dimensions (L×W×H) 82.0×77.0×146.0mm
Weight 246g
Notification Beep, LED
Operating Current 85mA(typical), 92mA(max.)
Interfaces USB
Operating Voltage 5VDC±5%
Light Intensity 0~15000lux(screen barcode)；0~120000lux(paper barcode)
Environmental
 Operating Temperature -20°C to 60°C (-4°F to 140°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Humidity 5%~95% (non-condensing)
ESD ±12 KV (air discharge);
±8 KV (contact discharge)
Drop 1.5m/4.9ft
Sealing IP52



Certifications
 IEC 62471. RoHS, CE, FCC
