WADE-8171 is based on Intel® Celeron® processor N3160. With dual-channel DDR3L memory and rich I/O sets, WADE-8171 empowers energy-efficient solutions for pointof-sale (POS) and industrial automation applications.
|
MODEL
|
WADE-8171
|
|
Form Factor
|
Mini-ITX
|
|
CPU
|
Intel® Atom® N3000 Family
|
|
Chipset
|
N/A
|
|
BIOS
|
AMI UEFI
|
|
Memory
|
2x DDR3L SO-DIMM up to 8GB
|
|
Expansion
|
1x PCIe x1 slot
2x mini-PCIe socket |
|
Display
|
VGA/HDMI/LVDS
|
|
Audio
|
Realtek ALC887 HDA codec
|
|
LAN
|
2x GbE
|
|
Serial Port
|
2x RS-232/422/485
4x RS-232 |
|
USB
|
4x USB3.0
4x USB2.0 |
|
Storage Device
|
2x SATA
|
|
GPIO
|
8 bit
|
|
Others
|
N/A
|
|
Dimension
|
170 x 170mm
|
| Ordering Guide | |
|---|---|
|
AB1-3D63
|
(R).WADE-8171-N3150
Mini-ITX ESB.Intel® Braswell Quad Core Celeron® 2.08GHz (6W). w/DDR3L/VGA/LVDS/ HDMI/dual GbE LAN/SATA |
| Packing List |
|---|
|
1x WADE-8171 motherboard
|
|
1x I/O shield
|
|
1x SATA cable
|
|
1x Driver CD
|
